Nav Auxichem offers high quality machine tapes for the graphic industry, mail handling & paper converting industry. These belts exhibit
- High co-efficient of friction for exceptional gripping
- Excellent directional stability.
- High resistance to abrasion, oil & solvents.
Technical Specifications
| Belt Grade | Top Cover | Reverse Cover | Traction Layer | Total Thickness | Shaft Load 1% | Min Pulley | Belt Weight approx. | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Material | Colour | Surface | Material | Colour | Surface | Material | (mm) | (N/mm) | (mm) | (Kg/Sq. mtr.) | |
| PF-0 IMP | NBR | Dark Green | Rough | PA6 Fabric | Green | - | Polyamide | 0.95 | 2.5 | 15 | 1.05 |
| PF-1 IMP | NBR | Dark Green | Rough | PA6 Fabric | Green | - | Polyamide | 1.3 | 5 | 30 | 1.4 |
| PF-2 IMP | NBR | Dark Green | Rough | PA6 Fabric | Green | - | Polyamide | 1.8 | 7.5 | 60 | 1.75 |
| FNF-20 IMP | PA6 Fabric | Green | - | PA6 Fabric | Green | - | Polyamide | 0.95 | 2.5 | 15 | 0.8 |
| FNF-35 IMP | PA6 Fabric | Green | - | PA6 Fabric | Green | - | Polyamide | 1.05 | 3.5 | 25 | 1.05 |
| FNF-60 IMP | PA6 Fabric | Green | - | PA6 Fabric | Green | - | Polyamide | 1.2 | 5 | 30 | 1.25 |
| FNF-100 IMP | PA6 Fabric | Green | - | PA6 Fabric | Green | - | Polyamide | 1.45 | 7.5 | 50 | 1.5 |
| FNF-120 IMP | PA6 Fabric | Green | - | PA6 Fabric | Green | - | Polyamide | 1.7 | 10 | 60 | 1.7 |
